Multiple sensor types
Supports resistive, 0–5 V, 4–20 mA and ultrasonic tank sensing.
SENSE PRODUCT FAMILY
TankSense
NMEA 2000 tank monitoring for the senders already aboard.
TankSense interfaces with resistive, pressure and ultrasonic marine tank sensors and broadcasts tank level, volume and status on the NMEA 2000 network.
Network connected
Publishes PGN 127505 Fluid Level for compatible chartplotters, Venus OS and SenseServer.
Built for existing tanks
Configure tank capacity, fluid type and calibration without replacing the tank.
DESIGNED FOR REAL BOATS
Modern tank data without replacing everything.
TankSense is designed around existing boats: proven senders, existing tanks and an NMEA 2000 backbone. Select the appropriate interface, configure the tank and make the information available across the vessel.
Supported interfaces
Resistive33–240 Ω / 0–180 Ω
Voltage0–5 V
Current4–20 mA
UltrasonicA02YYUW compatible
NetworkNMEA 2000 / 250 kbps
PRODUCT INFORMATION
Choose the interface that matches your sender.
Part numberProduct / InterfaceDescription
100-0001-00Resistive33–240 Ω sender
100-0001-01Resistive0–180 Ω sender
100-0002-00Pressure0–5 V sensor
100-0002-01Pressure4–20 mA sensor
100-0003-00UltrasonicUltrasonic level sensor
ORDER TANKSENSE
Select your sensor interface
Choose the TankSense version that matches the sender already installed on your boat.
DEVELOPMENT TEST PRICE$1.00
