Know what is deployed
Measures chain or rode deployment while allowing the windlass to operate exactly as it does today.
SENSE PRODUCT FAMILY
ChainSense
Anchor chain counter and NMEA 2000 anchoring solution.
ChainSense turns your existing windlass into a connected anchoring system. It measures chain or rode deployment, publishes information on NMEA 2000 and works with SenseServer for anchor position, geofence monitoring and remote alerts.
OLED and phone access
A local OLED provides immediate status while SenseServer makes anchoring information available by phone, tablet or computer.
Position and geofence
Store the anchor drop GPS position, define a geofence and receive email/SMS anchor-drag alerts through SenseServer.
DESIGNED FOR REAL BOATS
Add intelligence to the windlass you already own.
ChainSense senses existing windlass Up/Down controls and gypsy movement without interrupting normal operation. Chain-per-revolution, fixed chain, anchor position and geofence parameters turn simple deployment measurement into a connected anchoring tool.
Core functions
Windlass inputsUp / Down sense only
Gypsy inputReed switch / similar sensor
Local displayOLED
Anchor positionGPS via SenseServer
NetworkNMEA 2000 / 250 kbps
PRODUCT INFORMATION
ChainSense system.
Part numberProduct / InterfaceDescription
CS-100ChainSenseAnchor monitoring module
CS-KITInstallation KitCables, connectors, gypsy sensor and mounting hardware
Online purchasing for ChainSense is being prepared.
Buy ChainSenseTankSense is the first product being used to validate the ordering workflow.
